2018 Alta Motors REDSHIFT MX

Call for Price


New/Used
New
Usage
0 Miles
Availability
In Stock
Location
Triumph Motorcycles of Harrisonburg
Primary Color
White and Yellow
VIN
56PARABM0JB000221
Stock #
AL003
Title
Clean
Condition
Excellent
Year
2018
Manufacturer
Alta Motors
Model
REDSHIFT MX

Overview

Description

Designed as the electric equivalent of a modern 250, the Redshift MX is just as capable as a trail and woods bike as it is a MX2/Lites class motocrosser. The Redshift MX requires no air filters, oil changes or top end rebuilds, so you'll spend less time wrenching and more time riding. Join the growing ranks of riders who believe this is the most fun dirt bike ever built.

Traction Maps
  • Sport: Performance profile engineered to line up with 250f race machinery.
  • Eco: A traction map that offers the best range profile. Also a great map for just starting out.
  • Performance: Similar traits as the Sport map but with more bottom end and traction - it also makes a great starting gate map
  • Overclocked: Maximum torque and power are available without restriction - if you have the skill to control it. Thermal limiting will protect the machine if you push too hard.
Features
  • The Alta Pack: Mile for mile, there is no smaller, more compact, energy dense battery pack in transportation. The Alta Pack is waterproof rated up to IP67, is durable enough to handle shocks and vibes up to 20G, and is digitally self-monitoring. Our stacked honeycomb architecture allows for extreme energy density at 185 watt hours per kilogram, combined with a unique thermal wicking system to shed heat faster than any other lithium-ion transportation battery in production.
  • The Motor: Alta's liquid-cooled 14,000 RPM motor is pound for pound one of the most powerful in motorsports. It is optimized to the narrow width of the Redshift's bulkhead and is precisely located at the roll center of the bike. This placement allows for the lowest polar moment of inertia in motorcycling - drastically minimizing any gyroscopic impediment to handling. The Redshift's motor weighs 15lbs and puts out 42 HP at the countershaft and pushes power through a 3.5:1 gear reduction to deliver 38 lb-ft of torque at the motor from a dead stop at 0 RPM.
  • Redshift Bulkhead: The Redshift Bulkhead—the chassis core—functions as the outer motor casing, the cooling circuit for the motor and inverter, as well as the transmission case for the gear reduction. Additionally, it is the main structural hub, connecting to the rear suspension, the airframe, the forged monocoque chassis, and the trellis skidframe. All of this integration is coordinated with very specific strength, weight, and stiffness goals to produce the right ride and compliance characteristics at all lean angles, and under impact.
  • WP is the largest motorcycle suspension producer in Europe, and we chose their product for the Redshift due to their technical prowess and ease of tuning. WP competes globally at the highest levels of competition and that expertise combined with their willingness to try new things has resulted in the Redshift MX using WP 4CS suspension built to our own spec as developed by the team here at Alta Motors.
  • Since 1973 Acerbis has been producing high quality plastic bodywork and the company has worked with everyone from legends like Preston Petty to OEM manufacturers such as Yamaha. We're proud to partner with them on the production of our Redshift plastics and subframe in an effort to create the vision of Alta Motors and the future of fast.
  • Brembo S.P.A. is the gold standard for high performance brake systems on motorcycles. Founded in 1961, the Italian company produces a range of products that can be found on motorcycles on the street and the trail. The Redshift MX uses cast and machined Brembo calipers.
  • Warp 9 Racing is an American manufacturer of high performance motorcycle wheels. In a short amount of time Warp 9 Racing has gone from a boutique upstart to an OE supplier, offering some of the highest quality wheels on the market. We chose to work with Warp 9 Racing because their wheels are produced here in the US, and their exacting demands for quality and performance match our own.
Drivetrain
  • Power: 42 HP
  • Torque: 38 lb-ft Wheel
  • Motor: High Speed PMAC
  • Transmission: 1 Speed
  • Gear Ratio: 3.53 : 1
  • Major Maintenance Cycle: 1000 Hours
  • Sprockets: 12F / 53R
Battery
  • Type: Waterproof Li-Ion 350v
  • Capacity: 5.8kWh
  • Charger: Offboard
  • Recharge Time: 2 hrs(240v - Rapid) 4 hrs(120v - Standard)
  • Electronics: Alta-Digital, 4 Maps
Components
  • Front Fork: WP 4CS Fully Adjustable
  • Rear Shock: WP 5018-Link Fully Adjustable
  • Front Brake: Brembo Two Piston 260mm Rotor
  • Rear Brake: Brembo Single Piston 220mm Rotor
  • Wheels: Warp 9 Elite 21"F / 19"R
  • Tires: Bridgestone Battlecross X30
Specifications
  • Frame: Forged & Welded Aluminum
  • Swingarm: Permanent Mold Aircraft Aluminum
  • Weight: 265 lbs
  • Wheelbase: 59"
  • Seat Height: 37"
  • Rake: 26.9°
  • Adjustable Offset: 18/22mm
  • Warranty: 12 Months*
NOTES:
*Ask your dealer for additional details about Frame and Electrical Drivetrain Warranty

Specs

Engine

Engine Type
High Speed PMAC

Chassis

Front Suspension
WP 4CS Fully Adjustable
Front Brakes
Brembo Two Piston 260mm Rotor
Front Tire
Bridgestone Battlecross X30
Rear Suspension
WP 5018-Link Fully Adjustable
Rear Brakes
Brembo Single Piston 220mm Rotor
Rear Tire
Bridgestone Battlecross X30

Dimensions

Dry Weight
265 lb.
Wheelbase
59 in.
Seat Height
37 in.
Rake
26.9 deg.

Transmission

Transmission
1 Speed

General

Warranty
12 Months
